AlumaSeal® CS™
The AlumaSeal CS™ is an advanced sealing film designed to meet the rigorous demands of cold storage applications, featuring a robust 50 µm acrylic adhesive that remains effective at temperatures as low as -80 °C. Specially formulated for superior performance, this sealing film is not recommended for PCR or thermocycling, making it ideal for applications that prioritize preservation over thermal cycling.
Key Features:
- Specialized Composition: Made from 50 µm aluminum foil, AlumaSeal CS™ sealing films ensure maximum protection for your samples.
- Enhanced Cold Storage: Maintains integrity and performance in extreme temperatures down to -80 °C.
- Superior Barrier Properties: Effectively retards evaporation, safeguarding the quality of your samples.
- Piercing Capability: Easily pierced with pipet tips or robotic probes for hassle-free sample recovery.
Each sealing film features a convenient single non-perforated end tab that simplifies application. To utilize, simply hold the tab and carefully strip the backing from the body of the sealing film as it lays flat on the plate, preventing any curling during the process.
Specifications:
| SKU |
Liner Thickness |
Corner Radius |
Dimensions |
| FC-100 |
5.6 mil - 7.4 mil |
0.094" |
5.219" ± 0.015" x 3.208" ± 0.015" |
| FCS-25 |
5.6 mil - 7.4 mil |
0.094" |
5.219" ± 0.015" x 3.208" ± 0.015" |
Additional Info:
| SKU |
Tab Dimensions |
Film Material |
Film Thickness |
Adhesive Thickness |
Liner Material |
| FC-100 |
0.375" ± 0.015" |
Aluminum Foil |
1.8 mil - 2.2 mil |
1.8 mil - 2.2 mil |
White Poly-Coated Paper |
| FCS-25 |
0.375" ± 0.015" |
Aluminum Foil |
1.8 mil - 2.2 mil |
1.8 mil - 2.2 mil |
White Poly-Coated Paper |
Application Advancements:
For optimal sealing efficacy, using an accessory plate roller to apply the AlumaSeal CS™ sealing films ensures a secure and uniform seal around all wells on 96-well, 384-well, and 1536-well plates. For raised-rim plates, the paddle-type alternative offers an improved pressing method that fits seamlessly within the plate's rim, enhancing the sealing experience.
