Avante SureVac 22L Vacuum Autoclave

Avante SureVac 22L Vacuum Autoclave: Reliable Sterilization for Busy Facilities
The Avante SureVac 22L Vacuum Autoclave offers an efficient and cost-effective solution for facilities that require dependable sterilization. With a generous 22-liter capacity, this unit is perfect for those who handle high volumes of instruments needing sterilization.
Designed with the user in mind, the SureVac 22L features an intuitive microprocessor-controlled interface that ensures safe and straightforward operation. The digital display provides real-time indicators of parameters and conditions, allowing for quick monitoring during the sterilization process.
One of the standout features of the SureVac 22L is its automatic self-checking system, which protects against overheating or over-pressurization, providing peace of mind with every cycle. Additionally, the autoclave employs cool, filtered air at the end of each cycle to significantly reduce instrument turnaround time, enhancing overall workflow efficiency.
Safety is a top priority with the SureVac 22L. The interlocking door system automatically engages at the start of each cycle, ensuring a secure sterilization environment. This fully automatic unit also allows for controlled quick cycles and adjustable program parameters to cater to your specific needs. Its spacious chamber can accommodate three to five instrument trays, making it versatile for various applications.
Included with the unit are essential components such as a drain hose and adaptors, filters, as well as an autoclave rack and shelves. For those seeking enhanced documentation, a thermal printer option is also available.
Invest in the Avante SureVac 22L Vacuum Autoclave for reliable and efficient sterilization that meets the demands of modern medical and dental practices.

Avante SureVac 22L Vacuum Autoclave Specifications

General

• Autoclave Inner Chamber: 10 in x 17 in (25.4 cm x 43.2 cm)

• Outer Dimensions: 24 in D x 17.5 in W x 15.5 in H (61 cm D x 44.5 cm W x 39.4 cm H)

• Temperature of Environment: 41~104°F (5~40°C)

• Relative Humidity: ?80%

• Atmospheric Pressure: >10.15 psi (70 kPa)

• Frequency: 60 Hz

• Voltage: One-phase 110V ± 11V (± 5% tolerance)

Sterilization Processes

• 250°F / Universal:

• Sterilizing Time: 20 min

• Sterilizing Temperature: 250°F (121°C)

• Sterilization Pressure: 16.0 psi (110.3 kPa)

• Drying Time: 15 min

• 273°F / Loose Instruments:

• Sterilizing Time: 4 min

• Sterilizing Temperature: 273°F (134°C)

• Sterilization Pressure: 30.5 psi (210 kPa)

• Drying Time: 4 min

• 273°F / Universal:

• Sterilizing Time: 4 min

• Sterilizing Temperature: 273°F (134°C)

• Sterilization Pressure: 30.5 psi (210 kPa)

• Drying Time: 15 min

• 273°F / Cotton:

• Sterilizing Time: 4 min

• Sterilizing Temperature: 273°F (134°C)

• Sterilization Pressure: 30.5 psi (210 kPa)

• Drying Time: 20 min

• B-D Test:

• Sterilizing Time: 3.5 min

• Sterilizing Temperature: 273°F (134°C)

• Sterilization Pressure: 30.5 psi (210 kPa)

• Drying Time: 10 min

• Vacuum Test: 15 min
