BD Series Standard Classic Incubators with Gravity Convection
The BD Series Standard Classic Incubators with Gravity Convection are expertly engineered for long-term, stable continuous operation, making them ideal for the gentle incubation of organisms as well as the conditioning of heat-sensitive media or microbiological heating.
Key Features:
- Temperature Range: Ambient temperature plus 5°C to 100°C
- High Temperature Accuracy: Enhanced by APT.lin™ technology for precise control
- Gravity Convection: Ensures even temperature distribution
- Adjustable Exhaust Air Flap: Provides customizable airflow control
- Advanced Controller: Features built-in timer functions for ease of use
- Inner Door: Made of tempered safety glass for enhanced visibility
- Racking System: Comes with 2 chrome-plated racks; units up to 115 liters are stackable
- Safety Device: Class 3.1 independent temperature safety device (DIN 12880) with visual temperature alarm
- Computer Interface: RS 422 for easy data management and monitoring
Benefits:
- Reputable for safe and reproducible incubation, even under high batch loads in extended operational periods.
- The inner glass door promotes a stable atmosphere, crucial for sensitive experiments.
- Features a 100°C disinfection routine that ensures cleanliness and compliance with laboratory standards.
Specifications:
| SKU |
Temperature Range |
Temperature Fluctuation |
Temperature Variation |
Warm Up Time |
| 9010-0187 |
100°C +5°C |
± 0.2 at 37°C |
± 0.5 at 37°C |
59 min to 37°C |
| 9010-0189 |
100°C +5°C |
± 0.2 at 37°C |
± 0.5 at 37°C |
59 min to 37°C |
| 9010-0073 |
100°C +5°C |
± 0.1 at 37°C |
± 0.5 at 37°C |
120 min to 37°C |
| 9010-0176 |
100°C +5°C |
± 0.1 at 37°C |
± 0.5 at 37°C |
120 min to 37°C |
Additional Information:
| SKU |
# of Shelves |
Door Recovery Time |
Depth |
Height |
Width |
Power Requirement |
| 9010-0187 |
2 std./4 max. |
20 min |
20.49 in |
19.5 in |
17.14 in |
230 V, 50/60 Hz |
| 9010-0189 |
2 std./4 max. |
20 min |
20.49 in |
19.5 in |
17.14 in |
120 V, 50/60 Hz |
| 9010-0073 |
2 std./9 max. |
10 min |
30.14 in |
40.4 in |
48.7 in |
230 V, 50/60 Hz |
| 9010-0176 |
2 std./9 max. |
10 min |
30.14 in |
40.4 in |
48.7 in |
120 V, 50/60 Hz |
