BW0 High Temperature Standard Insulated Heating Tapes
The BW0 High Temperature Standard Insulated Heating Tapes offer a reliable solution tailored for laboratory heating applications including apparatus, gas tubing, and temporary heat. Designed for versatility, these premium Samox heating tapes employ multi-stranded resistance wire heating elements, ensuring exceptional flexibility and durability under demanding conditions.
Key Features:
- Maximum Exposure Temperature: Capable of withstanding temperatures up to 932°F (500°C) for single-use and up to 572°F (300°C) for removable/reusable applications.
- Surface Compatibility: Safe for use exclusively with glass and non-electrically conductive surfaces.
- Installation Ease: Comes with 9 in (230 mm) long high-temperature tie downs for straightforward mounting.
- Flexibility: Excellent flexibility that adapts to various shapes and surfaces.
- Rapid Thermal Response: Quickly reaches desired temperatures to meet heating demands.
- Power Lead Options: Choose between power leads located on the same end or opposite ends to suit your setup.
- Minimum Bend Radius: A compact bend radius of just 0.13 in (3 mm) for intricate applications.
Specifications:
| SKU |
Max Temperature |
Density |
| BW0052020L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0052040L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0052060L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0052080L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0102020L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0102040L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0051020L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0051040L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0051060L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0051080L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0101020L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
| BW0101040L |
Up to 572°F (300°C) |
13.1 W/in² (2.0 W/cm²) |
Additional Information:
| SKU |
Certification |
Material |
Plug Type |
Lead Length |
| BW0052020L |
IP5X |
Samox® knitted and braided |
Bare Wire Leads |
2 ft (0.6 m) |
| BW0052040L |
IP5X |
Samox® knitted and braided |
Bare Wire Leads |
2 ft (0.6 m) |
| BW0052060L |
IP5X |
Samox® knitted and braided |
Bare Wire Leads |
2 ft (0.6 m) |
| BW0052080L |
IP5X |
Samox® knitted and braided |
Bare Wire Leads |
2 ft (0.6 m) |
| BW0102020L |
IP5X |
Samox® knitted and braided |
Bare Wire Leads |
2 ft (0.6 m) |
| BW0102040L |
IP5X |
Samox® knitted and braided |
Bare Wire Leads |
2 ft (0.6 m) |
| BW0051020L |
REACH, RoHS, IP5X |
|
Separable 2-prong plug |
2 ft (0.6 m) |
| BW0051040L |
REACH, RoHS, IP5X |
|
Separable 2-prong plug |
2 ft (0.6 m) |
| BW0051060L |
REACH, RoHS, IP5X |
|
Separable 2-prong plug |
2 ft (0.6 m) |
| BW0051080L |
REACH, RoHS, IP5X |
|
Separable 2-prong plug |
2 ft (0.6 m) |
| BW0101020L |
IP5X |
|
Separable 2-prong plug |
2 ft (0.6 m) |
| BW0101040L |
IP5X |
|
Separable 2-prong plug |
2 ft (0.6 m) |
Note: A temperature controller is necessary for the safe operation of this product.
