EDU™ ADA Compliant Series Ductless Demonstration Fume Hood

EDU™ ADA Compliant Series Ductless Demonstration Fume Hood

Product Overview: The EDU™ ADA Compliant Series Ductless Demonstration Fume Hood combines cutting-edge design with essential safety features tailored for laboratory environments. This versatile fume hood is perfect for science class lectures, safety practice demonstrations, and laboratory assignments, offering an accessible, interactive workspace for all participants.

Key Features:

• Designed for wheelchair access, making it inclusive for all users.
• Convenient remote control access allows flexibility in operation.
• Provides 360° visibility to enhance learning and participation.
• Ensures safety by protecting users from toxic fumes.
• Filter replacement is simple and efficient.
• Improved filter clamping technology minimizes bypass leakage.
• Low airflow alarm alerts users to unsafe conditions.
• Meets ANSI, OSHA, AFNOR, and BSI safety standards.
• Portable unit with transparent walls for maximum visibility.
• Offers personnel and environmental protection while maintaining optimal energy efficiency with zero toxic emissions.
• Available with an optional stand that can be fitted with adjustable height legs or mobile locking casters.

Applications:

• Science Class Lectures
• Safety Practice Demonstrations
• Laboratory Assignments

Construction Details:

• Exterior cabinet manufactured in the USA with an epoxy-coated steel superstructure and clear panels.
• Front safety panels lift on hinges for easy interior access.
• Locking casters ensure easy transport between locations.
• Compact design allows for easy passage through standard doorways.

Docking Station Features:

• Prevents accidental service disconnects for mobile fume hoods.
• Key-locked for enhanced security and prevents unauthorized access.
• Available in recess or flush wall/bench-mounted versions.
• Includes isolated single switch electrical sockets (13 amp).
• Features quick-release connections for water, waste, and gas services.
• Optional RJ45 outlet available for additional connectivity needs.

Specifications:

SKU	Plug Type	Air Flow Rate	Construction	Construction Color
P10XL-CART-RC-P	NEMA 5-15P	145 CFM	Epoxy Steel Frame and Head Unit, Clear Sides and Back Panel	White

Additional Information:

SKU	Electrical Information	External Dimensions
P10XL-CART-RC-P	115V, 60Hz	34 in x 28.5 in x 83.5 in

Please Note: Air Science Filters are sold separately and are essential for operation. For optimal filtration and safety, submit the required Filter Application Form after purchase to ensure correct filter selection.
