Edwards nXDS Oil-Free Scroll Pumps
The Edwards nXDS Oil-Free Scroll Pumps elevate scroll vacuum technology, delivering improved performance and exceptional pumping capabilities. With a focus on quiet operation and extended service intervals, the NXDS series stands out as the ultimate dry pumping solution. This advanced pump design combines the latest innovations in scroll technology with an intelligent drive, all while retaining the hermetically sealed mechanism synonymous with the XDS series. This hermetic sealing ensures that the vacuum environment remains uncontaminated by bearing lubricant, and protects the bearings from any process gases being pumped.
Applications
Key Features
- Quiet Operation: Enhance your working environment with minimal noise disruption.
- Hermetically Sealed: Achieve a lubricant-free vacuum environment, ensuring a contamination-free process with no oil disposal.
- Low Power Consumption: Benefit from reduced operational costs and a lower total cost of ownership.
- Intelligent Controls: Enjoy flexibility with user-friendly controls, including manual and remote operation modes.
- Superior Vapor Handling: Ideal for a wide range of applications, effectively managing challenging vapor loads.
- Long Service Intervals: Maximize equipment uptime with extended intervals between maintenance.
Specifications
| SKU |
Operating Temperature Range |
Power Requirement |
Water Vapor Tolerance |
| NXDS6I-1PH |
5°C to 40°C |
115-230 V, 60/50 Hz, 1 Phase |
110 gh-1 |
| NXDS10I-1PH |
5°C to 40°C |
115-230 V, 60/50 Hz, 1 Phase |
145 gh-1 |
| NXDS15I-1PH |
5°C to 40°C |
115-230 V, 60/50 Hz, 1 Phase |
240 gh-1 |
Downloads
- Edwards nXDS Vacuum Pump Brochure
- Edwards nXDS Vacuum Pump for Analytical Applications
- Edwards nXDS Vacuum Pump for Research/Development
