Hazardous Location Undercounter Freezers
Engineered for high-risk environments, our Hazardous Location Undercounter Freezers are specifically designed to operate safely in areas prone to volatile or explosive conditions. With ATEX certification and non-sparking components, these laboratory freezers guarantee the safety of both users and sensitive materials.
Key Features:
- Microprocessor Temperature Controller: Ensures precise temperature regulation for optimal preservation of hazardous materials.
- Digital Temperature Display: Provides easy-to-read, real-time temperature monitoring.
- Alarms: Equipped with audible and visual high/low temperature alarms complemented by remote alarm contacts.
- Simulator Ballast: Comes with glass beads in a bottle for reliable temperature simulation.
- High-Density Insulation: Cabinet is foamed-in-place with EPA compliant high-density urethane foam for superior thermal efficiency.
- Security Features: Lockable doors for enhanced security, including a key mechanism.
- Durable Exterior: Constructed with white powder-coated steel to withstand demanding environments.
- Leveling Legs: Adjustable legs for easy stabilization on uneven surfaces.
Certifications & Compliance:
- Meets NFPA and OSHA guidelines for Hazardous Location, Class 1, Division II, Groups C & D standards.
Specifications:
| SKU |
Operating Temperature Range |
Certification |
Warranty |
Hinge |
| EF051WWW/0M |
-15°C to -25°C |
ETL Listed; Meets NFPA guidelines 45 and 70 |
2 Year |
Right |
Additional Information:
| SKU |
Dimensions |
Electrical Information |
Refrigerant |
Controller |
| EF051WWW/0M |
23.625 in x 23.625 in x 32.25 in |
115VAC, 60Hz, 1-PH |
R600a |
Microprocessor |
Important Notes:
- These units require hard-wiring in conduit; plugs are not provided to ensure safety in hazardous environments.
- For optimal ventilation and safety, a clearance of 4 inches is required around the unit.
