Chemglass Korzun Process Reactors with Glass Baffles (2 L - 50 L)
The Chemglass Korzun Process Reactors are expertly engineered to enhance mixing and agitation within the reaction chamber, closely simulating the performance of larger, glass-lined reactors. Offered in a range of sizes from 2 L to 50 L, these reactors are ideal for a variety of laboratory applications.
Key Features:
- Designed to increase agitation, mimicking the efficient performance of larger glass-lined reactors.
- Precision ground 3/4" top and lower tubing for optimal compatibility with compression fittings and a top jointed adapter.
- Available in both square and rectangular shapes, with options for open or closed bottom configurations, catering to specific experimental needs.
- The PTFE joint is uniquely offset, allowing baffles to be adjusted up to 1" toward the center, enabling versatile reactor setups.
- Baffles can be vertically adjusted within the reactor, providing additional flexibility during experiments.
- Hollow baffles facilitate the insertion of thermocouples, accommodating diameters ranging from 1/8 in to 1/4 in, ensuring precise temperature monitoring during reactions.
Included Components:
- Glass baffle for enhanced mixing efficiency.
- Glass-filled PTFE adapter for secure and reliable connections.
- Lower PTFE compression fitting to ensure leak-proof operation.
For pH electrode baffles, please refer to model CG-1872-B.
Specifications:
| SKU |
Joint Size |
Fitting Type |
| CG-1971-122 |
Adapter Joint Size: 45/50 |
Lower PTFE Compression Fitting: Closed Bottom |
| CG-1971-132 |
Adapter Joint Size: 45/50 |
Lower PTFE Compression Fitting: 1/4 in |
| CG-1971-136 |
Adapter Joint Size: 45/50 |
Lower PTFE Compression Fitting: Closed Bottom |
| CG-1971-120 |
Adapter Joint Size: 45/50 |
Lower PTFE Compression Fitting: Closed Bottom |
