Labmax™ Bottletop Dispensers

Get Quote Add to Quote List

Do you have a Labmax™ Bottletop Dispensers you want to sell?

We buy used equipment! Learn about selling

Manufactured by: Labnet International

Category: Supplies

Labnet International Labmax™ Bottletop Dispensers

Labmax™ Bottletop Dispensers

The Labmax™ bottle top dispenser is designed for professionals who require precision and efficiency in their laboratory procedures. Developed through extensive testing and collaboration with end-users, this innovative dispenser offers a range of advanced features suited for a variety of laboratory applications.

Key Features

Closed Circuit Air Purging System: Effectively eliminates air and bubbles, ensuring no valuable reagent is wasted during operation.

Reagent Guard Valve: A safety mechanism that prevents accidental reagent discharge when the dispenser is idle.

Integrated Swivel Neck: Enjoy 360° rotation for easy dispensing without disrupting the bottle connection.

Direct Displacement PTFE Piston: Guarantees accurate dispensing with reduced risk of contamination.

Quick Volume Adjustment: Locking rocker switch for precise and reliable volume increments.

Auto-Calibrating: No calibration required even after disassembly, ensuring consistent accuracy.

Autoclavable: Can be sterilized at temperatures up to 121°C, maintaining lab hygiene standards.

ISO 9001 Certified: Design and manufacturing processes adhere to stringent quality standards.

Product Materials

Piston: Direct displacing, PTFE with a PTFE coated Viton O-ring for durability.

Cylinder: Borosilicate glass encased in a transparent plastic safety coating to provide strength and visibility.

Housing: Constructed from polypropylene for enhanced performance and efficiency.

Spill Prevention Technology

The Labmax™ dispenser incorporates a unique closed-circuit air purging mechanism that ensures air and bubbles are efficiently cleared, preventing loss of valuable reagents. The reagent guard valve defensively activates to minimize the risk of leakage, simplifying lab operations without the need for discharge tube caps.

Locking Rocker Switch Adjustment

The Labmax™ is engineered for effortless maintenance, allowing quick disassembly for thorough cleaning. Its locking rocker switch permits swift volume adjustments, while the built-in zero point guarantees no calibration is needed after cleaning. Each dispenser is marked for compliance with ISO 9001 procedures.

Included Adapters

Each Labmax™ Bottletop Dispenser comes equipped with a set of adapters (24, 28, 38, and 45 mm), providing versatility for various bottle sizes and ensuring optimal compatibility for all laboratory applications.

Technical Specifications

SKU	Increments	Reproducibility CV%	Thread Finish	Tolerance
D5370-10	0.05, 0.10, 0.20, 0.50, 1.00, 2.00 mL	± 0.1%	33mm, 33mm, 33mm, 45mm, 45mm, 45mm	0.02, 0.04, 0.08, 0.15, 0.40, 0.80 mL
D5370-100	0.05, 0.10, 0.20, 0.50, 1.00, 2.00 mL	± 0.1%	33mm, 33mm, 33mm, 45mm, 45mm, 45mm	0.02, 0.04, 0.08, 0.15, 0.40, 0.80 mL
D5370-10HF	0.05, 0.10, 0.20, 0.50, 1.00, 2.00 mL	± 0.1%	33mm, 33mm, 33mm, 45mm, 45mm, 45mm	0.02, 0.04, 0.08, 0.15, 0.40, 0.80 mL
D5370-2	0.05, 0.10, 0.20, 0.50, 1.00, 2.00 mL	± 0.1%	33mm, 33mm, 33mm, 45mm, 45mm, 45mm	0.02, 0.04, 0.08, 0.15, 0.40, 0.80 mL
D5370-25	0.05, 0.10, 0.20, 0.50, 1.00, 2.00 mL	± 0.1%	33mm, 33mm, 33mm, 45mm, 45mm, 45mm	0.02, 0.04, 0.08, 0.15, 0.40, 0.80 mL
D5370-5	0.05, 0.10, 0.20, 0.50, 1.00, 2.00 mL	± 0.1%	33mm, 33mm, 33mm, 45mm, 45mm, 45mm	0.02, 0.04, 0.08, 0.15, 0.40, 0.80 mL
D5370-50	0.05, 0.10, 0.20, 0.50, 1.00, 2.00 mL	± 0.1%	33mm, 33mm, 33mm, 45mm, 45mm, 45mm	0.02, 0.04, 0.08, 0.15, 0.40, 0.80 mL
