Luer Lock and Luer Tip Syringes

Luer Lock and Luer Tip Syringes

Discover the precision and versatility of our Luer Lock and Luer Tip Syringes, designed for seamless connectivity across a variety of applications. These syringes provide universal connections, enabling rapid attachment of different needles or accessories, making them ideal for efficient workflows in analytical environments. Perfectly adapted for the transportation and storage of samples prior to analysis, these syringes are the go-to choice for professionals moving samples from the field to the laboratory.

Engineered from high-quality borosilicate glass, our syringes feature an inert design that accommodates both liquid and gas samples. They are suitable for a range of manual and dispensing/diluting applications, ensuring a dispensed volume accuracy of +/-1%. With a fluoropolymer resin-tipped plunger, these syringes excel in gas-sealing capabilities thanks to the secure interference fit between the plunger tip and the barrel. Notably, plungers are interchangeable among syringes of the same volume, enhancing convenience and usability.

Features:

• Autoclavable design—plunger should be removed and both heated and cooled gradually.
• Accuracy and reproducibility are contingent upon the operator's technique.
• Thread in Plunger Stem: 6-32 UNC.
• Meets International Standards for Traceability.

Specifications:

Borosilicate Glass Barrel OD	Scale Length
50 µL to 500 µL = 8 mm 1 mL = 9 mm 2.5 mL = 11 mm 5 mL = 14 mm 10 mL = 18 mm 25 mL = 27 mm 50 mL = 32.8 mm 100 mL = 40.8 mm	50 µL to 25 mL = 60 mm 50 mL = 84.2 mm 100 mL = 104 mm

Available Models:

SKU	Type
004230	Fixed Needle, Gas Tight Plunger, Luer Lock
005230	Fixed Needle, Gas Tight Plunger, Luer Lock
006230	Fixed Needle, Gas Tight Plunger, Luer Lock
007230	Fixed Needle, Gas Tight Plunger, Luer Lock
008025	Fixed Needle, Gas Tight Plunger, Luer Lock
008425	Fixed Needle, Gas Tight Plunger, Luer Lock
008760	Removable Needle, Gas Tight Plunger, Luer Lock
008960	Removable Needle, Gas Tight Plunger, Luer Lock
009462	Removable Needle, Gas Tight Plunger, Luer Lock
009660	Removable Needle, Gas Tight Plunger, Luer Lock
009760	Removable Needle, Gas Tight Plunger, Luer Lock
008160	Removable Needle, Gas Tight Plunger, Luer Lock Valve
008560	Removable Needle, Gas Tight Plunger, Luer Lock Valve
008770	Removable Needle, Gas Tight Plunger, Luer Lock Valve
008970	Removable Needle, Gas Tight Plunger, Luer Lock Valve
009472	Removable Needle, Gas Tight Plunger, Luer Lock Valve
009670	Removable Needle, Gas Tight Plunger, Luer Lock Valve
009770	Removable Needle, Gas Tight Plunger, Luer Lock Valve

Note: The images displayed are for representational purposes and may not correspond to the specific item.
