NSF Certified Built-In Undercounter Vaccine Freezers
The NSF Certified Built-In Undercounter Vaccine Freezers are expertly designed to meet the rigorous NSF/ANSI 456 Standard for Vaccine Storage. These high-performance freezers safeguard pharmaceuticals by maintaining optimal temperatures, reducing waste, and ensuring effective delivery during critical applications.
Features
- Microprocessor Controller: Provides precise temperature management for reliable operation.
- LED Display: Features a 0.1°C resolution for accurate temperature readings.
- Visual and Audible Alarms: Ensures immediate notification of temperature deviations for added safety.
- Compatibility: Works seamlessly with Pyxis®, Omnicell®, and AcuDose RX® systems.
- Foamed-In-Place Cabinet: Constructed with EPA compliant, high-density urethane foam for superior insulation.
- Durable Design: Finished in white powder-coated steel for a modern, resilient exterior.
- NEMA 5-15 Plug: Standard electrical configuration for easy installation.
- Side Wall Port: 3/4 inch diameter port for flexibility in installation.
- Leveling Legs: Adjustable legs ensure stability on uneven surfaces.
- Quiet Operation: Maintains a noise level of 49 dBA or less, perfect for clinical environments.
Certifications and Compliance
- UL, C-UL, ETL, and C-ETL listed for enhanced safety.
- Compliant with UL471 standards for reliability.
- ENERGY STAR certified for energy efficiency.
- Temperature monitor device (TMD) compliant with current CDC guidelines for vaccine storage.
- Compliant with NSF/ANSI 456 standards for vaccine storage with rigorous testing protocols.
Specifications
SKU |
Door Type |
Operating Temperature Range |
Compliance |
Warranty |
Hinge |
PH-ABT-NSF-UCBI-0420 |
Solid Swing Door |
-15°C to -25°C |
NSF/ANSI 456 |
2 Year |
Right |
PH-ABT-NSF-UCBI-0420-LH |
Solid Swing Door |
-15°C to -25°C |
NSF/ANSI 456 |
2 Year |
Left |
Additional Information
SKU |
Dimensions |
Electrical Information |
Refrigerant |
Controller |
Plug Type |
PH-ABT-NSF-UCBI-0420 |
23.75 in x 24.5 in x 33.375 in |
110-120 VAC, 15A |
R600a |
Microprocessor |
NEMA 5-15 |
PH-ABT-NSF-UCBI-0420-LH |
23.75 in x 24.5 in x 33.375 in |
110-120 VAC, 15A |
R600a |
Microprocessor |
NEMA 5-15 |
