Oakworks CFPM301 3-Motion Imaging Table


The Oakworks CFPM301 3-Motion Imaging Table is designed to enhance the efficiency and comfort of imaging procedures. This advanced table features a dynamic height adjustment capability, ranging from 25" to 43", making it one of the most versatile in the industry.

Key Features:


  • Three Powered Motions: Experience seamless operation with powered height adjustment, Trendelenburg tilt, and longitudinal travel for optimal positioning.
  • Patient Weight Capacity: Robust design supports a maximum weight capacity of 500 lbs (227 kg), ensuring stability and safety.
  • Extensive Height Range: With an impressive adjustable height range of 18" (46 cm), the CFPM301 offers flexibility for various imaging needs.
  • Trendelenburg Tilt: Achieve precise positioning with a +15/-11° Trendelenburg tilt to accommodate different clinical requirements.
  • Longitudinal Travel: The table features a 10" longitudinal travel, allowing for adjustments and improving patient access during procedures.
  • Ample Imaging Area: The integrated headrest top measures 22" x 84" (56 cm x 213 cm), complemented by 56" (142 cm) of metal-free imaging area to facilitate clear imaging results.

Elevate your practice's imaging capabilities with the Oakworks CFPM301 3-Motion Imaging Table, engineered for durability and ease of use in a clinical environment. Optimize patient care with this exceptional imaging solution.
Oakworks CFPM301 3-Motion Imaging Table Specifications:

General:
  • Patient Weight Capacity: 500 lbs. (227 kg)
  • Bariatric version available with 750 lbs. (340 kg) capacity
  • Optional Integrated Headrest Carbon Fiber Top: 22" W x 84" L (56 cm x 213 cm)
  • Rectangular Carbon Fiber Top: 24" W x 80" L (60 cm x 203 cm)
  • Warranty: 4 years parts, 1 year labor
  • Certifications: FDA listed, cETL approved, CE marked
  • Patient Safety Strap
  • Casters: 4" (10 cm)
  • Controls: Hand Control (all motions), Foot Control (all motions)

Table Top:
  • 1" Radiolucent Table Top Pad
  • 3 Cranial Positioning Pads (included with Integrated Headrest Top only):
  • (1) 2" thick x 12" square (5 cm x 30 cm)
  • (1) 4" thick x 12" square (10 cm x 30 cm)
  • (1) Crescent face rest pad

Motion Specifications:
  • Motion 1: Height range 25" - 43" (63 cm to 109 cm)
  • Motion 2: Trendelenburg tilt +15°/-11°
  • Motion 3: Longitudinal travel: 10" (25 cm)
