Respironics BiPap Vision Ventilatory Support System

Respironics BiPap Vision Ventilatory Support System

Introducing the Respironics BiPap Vision Ventilatory Support System, a cutting-edge solution designed for accurate, reliable, and customizable ventilatory support. This advanced system is engineered to provide exceptional care while ensuring patient comfort through a range of innovative features.

Key Features

Integrated Display Screen
The BiPap Vision is equipped with an integrated display screen that presents easy-to-read, real-time graphics in both waveform and bar scale formats. This user-friendly interface provides essential measured and calculated values that assist in effective ventilator management, including:

• IPAP

• Total Breath Rate

• Exhaled Minute Ventilation

• Percentage of Patient Triggered Breaths

• Exhaled Tidal Volume

• EPAP

• Ti/Tot

• Peak Inspiratory Pressure

• Patient or Total Leak

Versatile Modes
This ventilatory support system offers several essential modes to meet varied patient needs:

• CPAP and S/T Modes: Essential for maintaining airway patency and providing effective pressure support ventilation.

• Proportional Assist Ventilation (PAV) * /T: Enhances patient comfort and synchrony with independent adjustments of volume and flow assist, tailored to the patient’s specific disease state.

Oxygen Control
Experience precise oxygen control, allowing for the blending of oxygen concentrations from 21% to 100% directly within the unit, eliminating the need for auxiliary oxygen tubing attached to the mask.
Pressure Regulation at the Mask
The system's innovative pressure regulation mechanism ensures that therapy pressure is delivered accurately at the mask, automatically compensating for any variations to ensure optimal therapy.
Upgradeable Design
The flexible, upgradeable design of the BiPap Vision supports both present and future medical advancements, allowing users to adapt and enhance the system without needing to invest in new equipment for every update.
BiPAP® Auto-Trak Sensitivity™
This pioneering feature ensures optimal response to changing breathing patterns and circuit leaks. The Auto-Trak Sensitivity™ intelligently identifies leaks and adjusts sensitivity thresholds automatically, providing maximum comfort and efficiency with each breath.
The Respironics BiPap Vision Ventilatory Support System is your solution for advanced ventilatory care, combining reliability, comfort, and adaptability to meet the evolving needs of patients and healthcare providers alike. Explore the future of ventilatory support—where accuracy meets innovation.

Respironics BiPap Vision Ventilatory Support System Specifications:

Control Ranges and Increments: Parameters
| Parameters | Control Range | Control Increment |
|----------------------------------|---------------------------------|-------------------------|
| IPAP | 4 to 40 cm H2O (1.6 to 15.9 inHg) | 1 cm H2O (0.39 inHg) |
| EPAP | 4 to 20 cm H2O (1.6 to 7.9 inHg) | 1 cm H2O (0.39 inHg) |
| CPAP | 4 to 20 cm H2O (1.6 to 7.9 inHg) | 1 cm H2O (0.39 inHg) |
| Rate | 4 to 40 BPM | 1 BPM |
| Timed Inspiration | 0.5 to 3.0 sec | 0.1 sec |
| IPAP > Rise Time | 0.05 to 0.40 sec | 4 set points: 0.05, 0.1, 0.2, 0.4 sec |
| Oxygen Concentration (%O2)* | 21 to 100% | 4% from 21 to 25%
5% from 25 to 100% |

*With optional Oxygen Module

---

Control Ranges and Increments: Alarms
| Alarm | Control Range | Control Increment |
|--------------------------------|---------------------------------|-------------------------|
| High Pressure | 5 to 50 cm H2O (2.0 to 19.6 inHg) | 1 cm H2O (0.39 inHg) |
| Low Pressure | Disabled; 0 to 40 cm H2O (0 to 15.7 inHg) | 1 cm H2O (0.39 inHg) |
| Low Pressure Delay | 0 to 60 sec | 1 sec |
| Apnea | Disabled; 20 to 40 sec | 4 set points: Disabled, 20, 30, 40 sec |
| Low Minute Ventilation | Disabled; 1 to 99 L/min | 1 L/min |
| High Rate | 4 to 120 BPM | 1 BPM |
| Low Rate | 4 to 120 BPM | 1 BPM |

---

Display Ranges and Increments
| Parameters | Control Range | Control Increment |
|-----------------------------------------|----------------------------------|-------------------------|
| IPAP | 0 to 50 cm H2O (0 to 19.6 inHg) | 1 cm H2O (0.39 inHg) |
| EPAP | 0 to 50 cm H2O (0 to 19.6 inHg) | 1 cm H2O (0.39 inHg) |
| CPAP | 0 to 50 cm H2O (0 to 19.6 inHg) | 1 cm H2O (0.39 inHg) |
| Rate | 0 to 150 BPM | 1 BPM |
| Exhaled Tidal Volume (VT) | 0 to 4000 ml | 1 ml |
| Minute Ventilation (Min Vent) | 0 to 99 L/min | 1 L/min |
| Total Leak (Tot Leak) | 0 to 300 L/min | 1 L/min |
| Patient Leak (Pt. Leak) | 0 to 300 L/min | 1 L/min |
| Peak Inspiratory Pressure (PIP) | 0 to 50 cm H2O (0 to 19.6 inHg) | 1 cm H2O (0.39 inHg) |
| Percent of Patient Triggered Breaths (Pt. Trig) | 0 to 100% | 1% |
| Ti/Ttot | 0 to 100% | 1% |
