Manufactured by: Excel Scientific

Category: Plasticware

Excel Scientific ThermalSeal® RTS™

ThermalSeal® RTS™

The ThermalSeal RTS is expertly designed to deliver an exceptionally strong seal that effectively minimizes evaporation, making it an indispensable tool in any laboratory setting. Its unique silicone adhesive remains non-tacky until pressure is applied, creating a secure bond around the wells and perimeter of the plate. This characteristic makes it ideal for applications involving dry samples, such as soil, seeds, and insects, as the non-activated adhesive above the wells does not interfere with sample handling.

Key Features:

    • Pressure-activated, non-tacky silicone adhesive for enhanced sealing performance.
    • Certified DNase- and RNase-free, ensuring sample integrity and reliability.
    • Simplified handling and plate positioning due to the non-tacky adhesive, reducing error during setup.
    • Chemically resistant to a variety of solvents, including DMSO, acetonitrile, and methanol.
    • Compatible with flat-top, raised-rim, and non-skirted PCR plates, offering versatility in your laboratory processes.
    • High optical clarity and low auto-fluorescence for improved visibility during analysis.
    • Available in a convenient roll format for automated applications (ThermalSeal RTS Roll-Seal).
    • Each box includes a complimentary sealing paddle to aid in achieving optimal pressure during application.
    • Note: All sales are final. No refunds permitted except for manufacturer defects.

Application Tips:

    • Ensure sufficient pressure is applied to activate the silicone adhesive for effective sealing.
    • It is recommended to use multiple swipes of the sealing paddle in both directions to achieve optimal results.
    • Allow a wait period of 10 minutes or more before thermal cycling to enhance the bond between the film and the plate.

Specifications:

SKU Temperature Range Dimensions Liner Thickness
TSS-RTQ-100 -80°C to +105°C 5.500" ± 0.015" x 3.0833" ± 0.015" 2.0 mil ± 10%
TSS-RTQ-25 -80°C to +105°C 5.500" ± 0.015" x 3.0833" ± 0.015" 2.0 mil ± 10%
TSS-RTQS-50 -80°C to +105°C 5.500" ± 0.015" x 3.0833" ± 0.015" 2.0 mil ± 10%
RRTS-79x65 -80°C to +105°C 3.093" x 214' 2.0 mil ± 10%
