TSG Series General Purpose Glass Door Refrigerators

Get Quote Add to Quote List

Do you have a TSG Series General Purpose Glass Door Refrigerators you want to sell?

We buy used equipment! Learn about selling

Manufactured by: Thermo Fisher

Category: Laboratory Refrigerators, Glass & Solid Door

Thermo Fisher TSG Series General Purpose Glass Door Refrigerators

Thermo Fisher None - Laboratory Refrigerators, Glass & Solid Door

TSG Series General Purpose Glass Door Refrigerators

The TSG Series Glass Door Refrigerators are designed with the needs of clinical and research laboratory environments in mind, delivering optimal temperature control along with user-friendly features. Engineered for reliability and sustainability, these refrigerators utilize advanced hydrocarbon refrigerants that are both SNAP and F-Gas compliant, ensuring efficient operation while minimizing power consumption.

Key Features:

Built specifically for clinical and research laboratory applications

Operates quietly at less than 53 dB

Heat-free defrosting technology

Features double-pane glass doors for enhanced visibility and insulation

Equipped with four 2-inch casters; front casters are lockable for stability

Self-closing doors with a 90° stop prevent temperature fluctuations

Bright LED interior lighting for clear visibility of stored items

Multiple alarm systems including Hi/Lo temperature, door ajar, and power failure alerts

Controller with a 12-hour battery backup for continuity during power outages

Rear access port for easy maintenance and servicing

Keyed door locks compatible with popular E-lock adapters for added security

Remote alarm contacts for further monitoring and alerts

Certifications:

cULus certified

ENERGYSTAR certified for energy efficiency

Specifications:

SKU	Door Type	Operating Temperature Range	Certification	Warranty	Hinge
TSG5005GD	Dual Glass Swing Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor	Left and Right
TSG4505GA	Dual Glass Sliding Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor
TSG2305GD	Glass Swing Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor	Right
TSG1205GA	Glass Swing Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor	Right
TSG4505GD	Dual Glass Sliding Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor
TSG3005GA	Glass Swing Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor	Right
TSG1205GD	Glass Swing Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor	Right
TSG5005GA	Dual Glass Swing Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor	Left and Right
TSG3005GD	Glass Swing Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor	Right
TSG2305GA	Glass Swing Door	2°C to 8°C	cULus, ENERGYSTAR	4 Year Parts & Labor + 1 Year Compressor	Right

Additional Specifications:

SKU	External Dimensions	Internal Dimensions	Electrical Information	Refrigerant	Controller	Plug Type
TSG5005GD	37.8 in x 56.5 in x 78.5 in	28.5 in x 52.5 in x 58 in	208-230V	R290	Capacitive Touch	NEMA 6-15
TSG4505GA	36.6 in x 56.5 in x 78.5 in	26 in x 52.5 in x 58 in	115V	R290	Capacitive Touch	NEMA 5-15
TSG2305GD	37.8 in x 28 in x 78.5 in	28.5 in x 24 in x 58 in	208-230V	R290	Capacitive Touch	NEMA 6-15
TSG1205GA	30.5 in x 24 in x 73 in	21.8 in x 20 in x 52.4 in	115V	R290	Capacitive Touch	NEMA 5-15
TSG4505GD	36.6 in x 56.5 in x 78.5 in	26 in x 52.5 in x 58 in	208-230V	R290	Capacitive Touch	NEMA 6-15
TSG3005GA	37.3 in x 34 in x 78.5 in	28.5 in x 30 in x 58 in	115V	R290	Capacitive Touch	NEMA 5-15
TSG1205GD	30.5 in x 24 in x 73 in	21.8 in x 20 in x 52.4 in	208-230V	R290	Capacitive Touch	NEMA 6-15
TSG5005GA	37.8 in x 56.5 in x 78.5 in	28.5 in x 52.5 in x 58 in	115V	R290	Capacitive Touch	NEMA 5-15
TSG3005GD	37.3 in x 24 in x 78.5 in	28.5 in x 30 in x 58 in	208-230V	R290	Capacitive Touch	NEMA 6-15
TSG2305GA	37.8 in x 28 in x 78.5 in	28.5 in x 24 in x 58 in	115V	R290	Capacitive Touch	NEMA 5-15
