Welch Allyn CP 10 EKG Monitor

Welch Allyn CP 10 EKG Monitor

• High-Performance Electrocardiograph

The Welch Allyn CP 10™ Electrocardiograph (EKG) is designed to enhance clinical efficiency with its user-friendly features and cutting-edge technology. This state-of-the-art monitor allows for seamless entry of patient demographics via a full alphanumeric keyboard, ensuring quick and accurate data input. The CP 10 is equipped with advanced filters that optimize ECG trace quality, delivering reliable results every time.
Key Features:

• Comprehensive 12-lead Resting ECG: Provides standard ECG measurements for in-depth cardiac assessment.

• Backlit VGA LCD Screen: The 1/4 inch VGA screen enhances visibility, making patient data entry and results easy to read.

• High-Resolution Thermal Printing: Produces quality reports on 8.25 × 11 inch thermal paper, ensuring that all essential information is clearly presented.

• Versatile Printing Options: Select from multiple printout formats, including 3x4+1, 3x4+3, 6, and 12 channel configurations for flexibility in reporting.

• Automatic and Manual Operation: Offers users the choice to operate the device in either mode, accommodating different clinical settings.

• Optional Interpretation Software: Enhance your diagnostic capabilities with supportive software for interpreting ECG results.

The Welch Allyn CP 10 EKG Monitor is an essential tool for healthcare professionals, delivering precision, efficiency, and reliability in cardiac monitoring. Ideal for hospitals, clinics, and cardiology practices, this monitor is your partner in patient care.

Welch Allyn CP 10 EKG Monitor Specifications (Old)

General

• Dimensions: 15.5 × 17 × 4 inches (39.4 × 43.2 × 10.2 cm)

• Weight: 11.25 lbs (5.1 kg) including battery

• Waveform Display: Backlit VGA LCD, 3 channel lead groups

• Keyboard Type: Elastomer keypad with complete alphanumeric keys, soft-key menu, and dedicated function keys

• Paper Type: 8.25 × 11 inches (21 × 28 cm), Z-fold thermal paper, 200 sheets stored in paper tray

• Thermal Recorder: Computer-controlled dot array, 8 dots/mm

• Thermal Writer Speeds: 5, 10, 25, 50 mm/s

• Gain Settings: 5, 10, 20 mm/mV

• Report Print Formats:

• Automatic mode: 3+1, 3+3, 6 channel, 12 channel

• Rhythm mode: 6 channel with configurable lead groups or 12 channel

• Frequency Response: 0.05 to 300 Hz

• Digital Sampling Rate:

• 1,000 s/sec/channel for recording and analysis

• 10,000 s/sec/channel for pacemaker spike detection

• Power Requirement: Universal AC power supply (100-240 VAC at 50/60 Hz) 50 VA

• Battery: Lead acid gel rechargeable battery; prints up to 200 ECGs per charge

• Filters:

• High Performance Baseline Filters

• 40 Hz Muscle Tremor Filter

• AC Interference Filter (50/60 Hz)

• Safety and Regulatory Compliance: ANSI/AAMI EC11, Class I type CF defibrillation proof
