Wrist Action® Platform Shaker with Single Speed, 8-Place
The Burrell Scientific Model 75 Wrist Action® Shaker is engineered for precision and versatility in laboratory settings. With a standard operational speed of 385 oscillations per minute (± 10%), this shaker mimics the natural back-and-forth movement of the human wrist. Its unique adjusting lever allows users to switch from gentle swirling motions to robust agitation by varying the angle of movement from 1 degree to 15 degrees. While the oscillation speed remains constant, the distance traveled by the vessels during each oscillation increases with the adjustment of the lever arm setting.
Key Features:
- Integrated timer for continuous operation or preset durations ranging from 1 to 60 minutes.
- User-friendly control panel featuring an On/Off (I/O) rocker switch that doubles as an overload protection device.
- Lever arm adjustment for precise control over agitation amplitude.
- Includes a molded rubber locking tool to prevent unwanted movement of the lever arm.
- Comprehensive manual available for detailed operational guidance.
Package Includes:
- Top platform tailored to your order specifications.
- Platform clamps as per your order specifics.
- Access to operating manual via QR code.
- Molded stopper serves as a lever arm brake.
- Power cord for seamless operation.
Specifications:
| SKU |
Max Capacity |
Timer Range |
Hertz |
| B7650819-EACH |
10 lb |
1 - 60 min or Continuous |
60 Hz |
Additional Information:
| SKU |
Material |
Dimensions |
Certification |
Color |
| B7650819-EACH |
Steel/Aluminum |
17.5 in x 17.5 in x 12 in |
Complies with UL/CSA standards |
Blue and White |
