AC200 Immersion Circulators

The AC200 Immersion Circulator is engineered for applications that demand superior pumping performance, precise temperature control, and robust safety features. With a temperature range spanning from -50°C to +200°C, it is expertly designed to meet a wide variety of laboratory needs, all while ensuring optimal efficiency and reliability.

Key Features

• Maximum temperature capability of 200°C
• Low-liquid level alarm to ensure safety (Safety Class III)
• Automatic shutdown feature upon detection of excess temperature, low liquid levels, or motor overload
• Versatile communication options: USB port, RS-232, RS-485, Ethernet/LAN, and Analog I/O
• Programmable application temperature alarm with user-defined settings for alarm, go-safe-state, or shutdown
• Self-Tuning PID controller for accurate temperature management
• 10-step ramp programming with real-time editing during run or pause
• Comprehensive range calibration of multiple points
• Real Temperature Adjustment (RTA) for enhanced calibration accuracy
• Choice of internal or external temperature control mode (Remote Sensor, NAMUR type)
• Adjustable pump speed with three levels for optimal turbulence control
• Powerful force and suction pump suitable for both open and closed applications
• User-friendly interface available in English, German, and French
• Customizable digital display resolution between 0.1 and 0.01 degrees, with options for °C, °F, or °K
• Acoustic and visual alarm indicators for real-time monitoring
• Auto-Restart function after power failure for seamless operation
• USB port designed for remote control functionality
• Built-in real-time clock for accurate time tracking
• Multi-functional port for connectivity

Additional Options

• Booster pump for increased performance (1 bar extra)
• Booster heater (2kW extra) for enhanced temperature control
• Auto refill device for convenient liquid management
• Magnetic/solenoid valve box for tap-water cooling control

Included Components

Each AC200 unit includes 8mm and 12mm hose barbs with a bridge, a pump plug for external circulation, and a 6-foot power cord.

Specifications

Specification	1560001	1560006	1560008	1560021	1560026	1560028
Heating Capacity (Metric)	2 kW / 1.2 kW	2 kW / 1.2 kW	2 kW / 1.2 kW	2 kW / 1.2 kW	2 kW / 1.2 kW	2 kW / 1.2 kW
Exterior Height	14.6 in. (37.2 cm)	14.6 in. (37.2 cm)	14.6 in. (37.2 cm)	14.6 in. (37.2 cm)	14.6 in. (37.2 cm)	14.6 in. (37.2 cm)
Voltage	230V	100V	115V	230V	100V	115V
Hertz	50Hz	50/60Hz	60Hz	50Hz	50/60Hz	60Hz
Exterior Length	7.8 in. (19.9 cm)	7.8 in. (19.9 cm)	7.8 in. (19.9 cm)	7.8 in. (19.9 cm)	7.8 in. (19.9 cm)	7.8 in. (19.9 cm)
Flow Rate	20 L/min.	20 L/min.	20 L/min.	20 L/min.	20 L/min.	20 L/min.
Max Pressure	475 mbar / 6.89 psi	475 mbar / 6.89 psi	475 mbar / 6.89 psi	475 mbar / 6.89 psi	475 mbar / 6.89 psi	475 mbar / 6.89 psi
Max Suction	330 mbar / 4.85 psi	330 mbar / 4.85 psi	330 mbar / 4.85 psi	330 mbar / 4.85 psi	330 mbar / 4.85 psi	330 mbar / 4.85 psi
Max Temperature (Metric)	200°C	200°C	200°C	200°C	200°C	200°C
Model	AC200	AC200	AC200	AC200 with bridge	AC200 with bridge	AC200 with bridge
Net Weight	9.25 lb. (4.2 kg)	9.25 lb. (4.2 kg)	9.25 lb. (4.2 kg)	9.25 lb. (4.2 kg)	9.25 lb. (4.2 kg)	9.25 lb. (4.2 kg)
Temperature Stability	0.01°C	0.01°C	0.01°C	0.01°C	0.01°C	0.01°C
Exterior Width	6.4 in. (16.5 cm)	6.4 in. (16.5 cm)	6.4 in. (16.5 cm)	6.4 in. (16.5 cm)	6.4 in. (16.5 cm)	6.4 in. (16.5 cm)
Safety Class	3/FL	3/FL	3/FL	3/FL	3/FL	3/FL
Certifications/Compliance	CE, RoHS	CE, RoHS	CE, RoHS	CE, RoHS	CE, RoHS	CE, RoHS
Dimensions (L x W x H) Exterior	7.8 x 6.4 x 14.6 in. (19.9 x 16.5 x 37.2 cm)	7.8 x 6.4 x 14.6 in. (19.9 x 16.5 x 37.2 cm)	7.8 x 6.4 x 14.6 in. (19.9 x 16.5 x 37.2 cm)	7.8 x 6.4 x 14.6 in. (19.9 x 16.5 x 37.2 cm)	7.8 x 6.4 x 14.6 in. (19.9 x 16.5 x 37.2 cm)	7.8 x 6.4 x 14.6 in. (19.9 x 16.5 x 37.2 cm)
Electrical Requirements	230V 50Hz	100V 50/60Hz	115V 60Hz	230V 50Hz	100V 50/60Hz	115V 60Hz
