Datex Ohmeda 3800 Pulse Oximeter

Do you have a Datex Ohmeda 3800 Pulse Oximeter you want to sell?

We buy used equipment! Learn about selling

Manufactured by: Datex-Ohmeda

Category: Pulse Oximeters (SpO2)

Datex-Ohmeda Datex Ohmeda 3800 Pulse Oximeter

Description for the Datex Ohmeda 3800 Pulse Oximeter


Introducing the Datex Ohmeda 3800 Pulse Oximeter, a state-of-the-art medical device designed to deliver accurate and reliable readings in diverse clinical environments. Featuring an easy-to-use interface and an intuitive feature set, this pulse oximeter is equipped with advanced TruTrak® + technology, a proprietary clinical motion algorithm that adeptly identifies, quantifies, and corrects patient motion to ensure precise monitoring.

Key Features


  • TruTrak+ Technology: This innovative algorithm effectively compensates for patient movement, enhancing the accuracy of readings during various clinical situations.

  • Relative Perfusion Index™ (PIr): The always-visible numeric value offers quick insights into pulse strength, assisting healthcare professionals in making informed decisions rapidly.

  • Plethysmographic Waveform: Provides visual reinforcement of clinical decisions, allowing for better assessment of a patient’s condition.

  • User-Friendly Display: The backlit, always-on screen not only highlights large, easy-to-read numbers but also ensures visibility even in low-light conditions.

  • Dedicated Function Keys: Navigate effortlessly through functions with dedicated keys and a simple menu system, eliminating the confusion of hidden features.

  • Continuous Alarm Monitoring: Alarm limits are displayed continuously, providing immediate visual cues for swift decision-making.

  • Durable and Reliable: Crafted to exceed international durability standards, the Datex Ohmeda 3800 undergoes extensive stress testing to ensure reliability in demanding clinical environments.

  • Universal Compatibility: Fully compatible with all patient types, the device utilizes OxyTip®+ sensors and cables to provide flexibility across various medical situations.

Ideal for hospitals, clinics, and emergency settings, the Datex Ohmeda 3800 Pulse Oximeter is the trusted choice for healthcare professionals seeking precision, clarity, and ease of use in patient monitoring. Enhance your clinical practice with this essential medical device.

Datex Ohmeda 3800 Pulse Oximeter Specifications


Physical Weight & Dimensions

  • Height: 3.7 inches (9.4 cm)
  • Width: 9.5 inches (24.4 cm)
  • Depth: 8.9 inches (22.5 cm)
  • Weight: 6.1 lbs (2.8 kg)

SpO2

  • Calibration: Functional
  • Accuracy (1 standard deviation):
  • 70 to 100% (±2 digits)
  • 70 to 100% (±3 digits during conditions of clinical patient motion with TruTrak+ enabled)
  • Below 70% (unspecified)
  • Range: 0 to 100%
  • Resolution: 1%

Pulse Rate

  • Range: 30 to 255 beats per minute (bpm)
  • Accuracy (assuming a constant pulse rate): ±2% or ±2 bpm (whichever is greater)
  • Accuracy (during conditions of clinical patient motion): Unspecified
  • Resolution: 1 bpm

Relative Perfusion Index (PIr) Pulsatile Value

  • Range: 0.00 to 9.99
  • Averaging Interval: 12 seconds
  • Resolution: 0.01

Alarm Limits

  • Low SpO2: OFF or 50 to 100% (preset 85%)
  • High SpO2: 50 to 100% or OFF (preset OFF)
  • Low Pulse: OFF or 30 to 235 bpm (preset: adult = 40 bpm, neonate = 100 bpm)
  • High Pulse: 30 to 235 bpm or OFF (preset: adult = 130 bpm, neonate = 200 bpm)

Alarm Silence

  • 2-minute silence (automatic on startup), all mute capability.

Signal Validation

  • Relative Perfusion Index Pulsatile value with PerfTrak® waveform display.

Memory

  • 12-hour data storage for SpO2, pulse rate, and alarm conditions (1 data point every 6 seconds).

SpO2 Calculation

  • 30 values per second / 60 Hz
  • 25 values per second / 50 Hz

Display

  • Digital: LED
  • Waveform: Backlit LCD

SpO2 Averaging Modes

  • Selectable 3, 6, or 12 seconds (short, medium, long) preset = 12 seconds (long)

Diagnostics

  • Automatic self-test on startup, continuous memory tests during operation.

Outputs

  • Serial (SpO2, pulse rate, alarms, error messages, and trend data).

Electrical Specifications

  • Battery: 8 volt, 3.2 ampere-hours sealed lead-acid. Continuous charge while operating on AC.
  • Charge Time: 100% capacity ~ 8 hours; 80% capacity ~ 4 hours.
  • Operation Time: ~ 5.5 hours on fully charged battery.
  • Low Battery Indicator: "Low Battery" displayed when < 5 minutes remaining.
  • Overload Protection: 2 ampere 250V fuses.
  • Power Consumption: 15 watts typical.
  • Input Voltage: 100 to 240 V, 50/60 Hz.
