Philips Intellivue Module M3001A - A03C06 - Masimo SET SPO2, NIBP, ECG, Temp, IBP

Experience unmatched patient monitoring with the Philips IntelliVue Module M3001A, equipped with the advanced parameter option A03C06, featuring Masimo SET SPO2, NIBP, ECG, Temp, and IBP capabilities. This state-of-the-art MMS module provides comprehensive and reliable monitoring for critical care environments. Designed for seamless integration, the M3001A ensures accurate blood oxygen saturation (SPO2), non-invasive blood pressure (NIBP), electrocardiogram (ECG), temperature, and invasive blood pressure (IBP) readings.
Thoroughly tested and meticulously cleaned by skilled biomedical technicians, the Philips IntelliVue M3001A is ready to deliver optimal performance in your clinical setting. Its compact design and intuitive interface make it a valuable addition to any medical facility looking to enhance patient care with top-tier monitoring technology. Upgrade your monitoring capabilities today with the Philips IntelliVue Module M3001A.

Philips Intellivue Module M3001A

• A03C06 Specifications:

• SpO2 Measurement:

• Technology: Masimo SET

• Range: 0% to 100%

• Accuracy: ±2% (70% to 100%), unspecified (0% to 69%)

• NIBP (Non-Invasive Blood Pressure):

• Measurement Range: 30 to 270 mmHg (4 to 36 kPa)

• Accuracy: ±5 mmHg (±0.67 kPa)

• ECG (Electrocardiogram):

• Leads: 3-lead, 5-lead options

• Frequency Response: 0.05 to 150 Hz

• Sensitivity: Adjustable

• Temperature Measurement:

• Type: Thermistor or digital probe

• Range: 32°C to 43°C (89.6°F to 109.4°F)

• Accuracy: ±0.1°C (±0.2°F)

• IBP (Invasive Blood Pressure):

• Measurement Range: -50 to +300 mmHg (-6.67 to 40 kPa)

• Accuracy: ±2% of reading

• Power Supply:

• Voltage: 100 to 240 VAC

• Frequency: 50/60 Hz

• Physical Dimensions:

• Size: 8.7 in x 6.3 in x 1.7 in (22.0 cm x 16.0 cm x 4.3 cm)

• Weight: 1.5 lbs (0.68 kg)

• Communication Ports:

• Interfaces: Ethernet, Serial, USB

• Operating Environment:

• Temperature: 0°C to 40°C (32°F to 104°F)

• Humidity: 15% to 95% (non-condensing)

• Storage Conditions:

• Temperature: -20°C to 60°C (-4°F to 140°F)

• Humidity: 10% to 95% (non-condensing)

Note: Ensure compatibility with other devices when integrating with healthcare systems. Always refer to the official documentation for detailed operational instructions.
