BTpro Botanical Vacuum Pumps
Experience exceptional performance with the BTpro Botanical Vacuum Pumps, engineered to meet the rigorous demands of rotary evaporators, glass reactors, purge ovens, and winterization filtration systems. With a focus on speed and purity, these pumps are ideal for a wide range of applications in the laboratory and industrial settings.
Key Features:
- High Flow Rate: Achieve faster processing times with superior flow rates tailored to your specific equipment needs.
- Deep Vacuum Capability: Attain a remarkable vacuum depth of 15 Torr, ensuring higher purity levels for your samples.
- Chemical Resistance: Constructed with fluoroplastic wetted surfaces, these pumps exhibit exceptional chemical resistance, assuring a longer service life.
- Oil-Free Operation: Designed to operate without oil, resulting in low maintenance requirements and cleaner operation.
Specifications:
| SKU |
Horsepower (H.P.) |
Max Vacuum |
Air Displacement |
Motor Power |
| 7030-01 |
1/2 HP |
29.7 in Hg |
100 L/min @60Hz |
0.7 kW @ 50 Hz, 0.85 kW @ 60Hz |
| 7010-01 |
1/5 HP |
29.3 in Hg |
40 L/min @60Hz |
0.7 kW @ 50 Hz, 0.85 kW @ 60Hz |
| 7020-01 |
1/5 HP |
29.3 in Hg |
70 L/min @60Hz |
0.7 kW @ 50 Hz, 0.85 kW @ 60Hz |
| 7040-01 |
0.6 HP |
29.7 in Hg |
170 L/min @60Hz |
0.7 kW @ 50 Hz, 0.85 kW @ 60Hz |
Additional Information:
| SKU |
Material |
Dimensions |
Certification |
Power Requirement |
Pump Connections |
Plug Type |
Ambient Temperature Range |
| 7030-01 |
PTFE |
9 in x 15 in x 7 in |
cUL |
115V, 60Hz, 1 Phase |
NW16 |
NEMA 5-15 |
10°C - 40°C |
| 7010-01 |
PTFE |
12 in x 7 in x 8.3 in |
CSA |
115V, 60Hz, 1 Phase |
3/8 in Barb |
NEMA 5-15 |
10°C - 40°C |
| 7020-01 |
PTFE |
13.8 in x 6.8 in x 8.8 in |
CSA |
115V, 60Hz, 1 Phase |
3/8 in Barb |
NEMA 5-15 |
10°C - 40°C |
| 7040-01 |
PTFE |
21 in x 11 in x 12 in |
cUL |
115V, 60Hz, 1 Phase |
NW16 |
NEMA 5-15 |
10°C - 40°C |
